Description

Model: XM-18
Size: 15.8 * 8.6 * 7.8 cm
Operating voltage: 180v-240v,50HZ
Weight: 0.75 kg
Temperature display range: 0-99.9 ℃
Temperature control precision: ±0.1 ℃
Moisture display range: 0-99.9%RH
Humidity control accuracy: 3%RH
Relative humidity: less than 85%
Ambient temperature: – 20 ℃ ~ 70 ℃

Number of eggs: up to 999

Egg cycle: 0-999 minutes (factory set at 90 minutes)

Egg turning time: 0-999 seconds (factory setting is 180 seconds)

Ventilation cycle: 0-999 minutes (factory set at 120 minutes)

Air change time: 0-999 seconds (factory setting is 15 seconds)

Output current: main and auxiliary heating 30A; other outputs are 10A;

number of output channels: 6 channels (main heating, auxiliary heating, exhaust [ventilation], left turning, right turning, humidification

Main Technical Index:

1. Temperature Measuring Range: 0-99℃

2. Temperature Measurement Accuracy: ±0.1℃

3. Humidity Measurement Range: 0—99%RH

4. Humidity Accuracy: ±3%RH

5. Number of signal output: 7, (over-temperature, temperature control, insufficient temperature, egg left-turning, egg right-turning, humidity control, alarm)

6. The maximum output load current: temperature control, insufficient temperature ≤ 8A/AC220V, over-temperature, egg left-turning, egg right-turning, humidity control, alarm ≤ 1A / AC22

7. Number of egg-turning: the maximum record is 999 times.

8. cycle of egg-turning: adjustment of 0 – 999 minutes (the factory default is 90 minutes)

9. egg-turning time: adjustment from 0 to 999 seconds (the factory default is 180 seconds)

10.ventilation cycle: from 0 to 999 minutes (the factory default is 120 minutes)

11. ventilation time: from 0 to 999 seconds (the factory default is 30 seconds)

12. Temperature measurement length: About 2 meters

1.Working Voltage: AC 160V – 240V,50HZ

2. Relative Humidity: less than 85% RH

3. Environment Temperature: –10℃ – 60℃

Specifications:

Digital displaying of temperature, humidity and turning frequency Full automatically temperature controlling Full automatically humidity controlling Full automatically eggs turning Full automatically alarming Full automatically cooling and ventilator Back emergency system
