Description

Standard Features
 Maximum speed 5 ips (127 mm/sec)  OpenACCESS™
design for easy media loading
 203 dpi print resolution (8 dots/mm)  Direct thermal (d) and Thermal transfer (t) printing of
bar codes, text, and graphics
 Fully-enclosed 5.0″ (127 mm) media compartment  Dual-wall frame construction
 ZPL II® programming language
 EPL2 page mode programming language
 EPL Line Mode support (GK420d)  32 bit RISC processor  8 MB Standard SDRAM memory (3 MB available to
user)  4 MB Standard Flash memory (1.5 MB available to
user)  Zebra E3™ Printhead Energy Control  Triple communications interface: Serial, USB & Parallel  User interface feed button (ZPL® style)  Odometer for print length tracking
 Unicode™
compliant for multi-language printing
 Auto-calibration of media
 16 resident expandable bitmap fonts (ZPL language)  One resident scalable font (ZPL language)  5 resident expandable bitmap fonts (EPL language)  Auto-switching 100-240V power supply
 IEC 60601-1 Certified (GK420 Healthcare models only)  Transmissive and reflective media sensing
 Head-up sensor  Programmable print speed: 2, 3, 4 & 5 ips
(51, 76, 102, 127 mm/sec)  Standard tear-off mode feature
 Zebra printer driver for Windows®
 ENERGY STAR® 2.0 qualified
